The Owner's Insights on the Gentech 25L Long Range Fuel Tank
Most Gentech generators run a small tank, and on a long job that means stopping to refuel while you're still working. Twenty-five litres fixes that. Same generator, same footprint, a lot more running time.
The important bit is that it's factory fitted. You order it with the generator and it comes built in, sitting inside the frame rather than bolted on the outside. That keeps the balance right and the centre lifting point where it should be.
There are two versions and they aren't interchangeable. The 25mm frame tank suits 5.9kVA and larger models. The 32mm frame tank suits the 8kVA RCD and R/S units only. Pick yours from the Frame option above, and if your model isn't obvious from the list, ring us and we'll match it.
Why You'll Love the Gentech 25L Long Range Fuel Tank
- 25 litres of fuel. Far longer between refuels than the standard tank.
- Sits inside the frame. Your generator keeps the same footprint on the tray.
- Centre point lifting kept. Still lifts and balances the way it was designed to.
- Factory fitted. Comes built in with your generator, not a DIY retrofit.
- Two frame options. Pick 25mm or 32mm above to match your generator.
- Made by Gentech. Engineered for the frame, not a universal tank.
Why You Should Consider a Gentech Generator Fuel Tank
This is Gentech's own long range tank, built to fit inside their generator frames rather than hang off them. See the rest of the Gentech range.
Gentech 25L Long Range Fuel Tank Specifications
| Capacity | 25 litres |
| Fitment | Inside the generator frame |
| Lifting | Integrated centre lifting point |
| Installation | Factory installed when ordered with a generator |
| 25mm frame option | 10-N3-LTR-009-25MM, suits 5.9kVA and larger (excludes 8kVA RCD and R/S, welders, workstations and diesel units) |
| 32mm frame option | 10-N3-LTR-009-32MM, suits 8kVA RCD and R/S units only |
| Brand | Gentech |
Work out which version you need first
There are two part numbers and they suit different frames. The 25mm frame tank covers 5.9kVA and larger models, but not the 8kVA RCD and R/S units, welders, workstations or diesels. The 32mm frame tank is for the 8kVA RCD and R/S units only. Choose yours from the Frame option above, and since it's factory fitted, get it right at order time rather than afterwards. If your generator isn't in the list, ring the store on 03 7056 6732 with the model number and we'll confirm which one goes on it.
Why an in-frame tank beats a jerry can
A jerry can means stopping, shutting down, waiting for the engine to cool and pouring fuel, several times a shift on a busy job. Twenty-five litres built into the frame means you fill it once and keep working. It also stays inside the roll cage, so it's protected the same way the rest of the generator is, and the centre lifting point still sits where the crane hook expects it.
Order it with the generator, not after
This is fitted at the factory when the generator is built, which is what makes the fit and finish right. It isn't a bolt-on you add later. So if you think you'll want the long range tank, decide before the generator ships rather than after it arrives. Call the store on 03 7056 6732 and we'll put the order together properly.
What's Included
- Gentech 25L long range fuel tank in the frame variant you select
- Factory installation with your generator order
What's Not Included
- The generator itself
- Fuel
- Retrofitting to a generator you already own
The tank is fitted at the factory as part of your generator order, so it arrives already installed. Choose the 25mm or 32mm frame above to match your model. It isn't sold as a retrofit for a generator you already have.
Not Sure Which Generator Fuel Tank Suits You?
The 25L long range tank suits you if you're ordering a Gentech generator and you want to stop refuelling mid-job. It's the wrong pick if you already own the generator, since it's factory fitted rather than retrofitted. Not sure which frame variant your model takes? Call the store on 03 7056 6732 with the generator model and we'll match it before you order.
